All-In-One Storage Batteries
Supports parallel use with multiple units and features a quick-connect plug for effortless expansion
Natural cooling reduces the power consumption of the entire model
A-grade battery cells are meticulously selected to ensure a 10-year service life
The modular design is easy to install and easy to maintain
Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit
Function buttons, easy to quickly check the working status of the host
The unique vertical standing design, the moving pulley is easy to move
Large capacity, high circulation, safe and stable
Batteries & Inverter
| Batteries Parameters | |
| Rated Voltage | 51.2V |
| Rated Capacity | 314Ah |
| Rated Energy | 16076Wh |
| Weight | 160Kg |
| Dimensions(L*W*H) | 1313*484*345±4mm |
| Maximum Charging Current (A) | 200A |
| Maximum Discharge Current (A) | 200A |
| Voltage Range (V) | 46.4~58.4 |
| Operating Temperature | 0°C~50°C |
| Number of Cycles | ≥ 6000 at 25℃ |
| Methods of Communication | CAN /RS485/RS232 |
| Storage Temperature | 10°C~60°C |
| PV String Input Data | |
| Maximum Input Power (W) | 11000 |
| Maximum Input Voltage (V) | 450 |
| MPPT Operating Voltage Range (V) | 120~430 |
| Starting Voltage (V) | 150 |
| Nominal Input Voltage (V) | 300 |
| Number of MPPTs | 2 |
| Each MPPT Controls the Number of PV Strings | 1 |
| AC Output Data | |
| Rated Output Power(W) | 10000 |
| Nominal Output Current (A) | 43 |
| Nominal Output Voltage (V) | 220/230/240 |
| Nominal Output Frequency(Hz) | 50/60 |
