LiFePO4 Storage Batteries Pack
Supports parallel use with multiple units and features a quick-connect plug for effortless expansion
Natural cooling reduces the power consumption of the entire model
Featuring IP65 waterproof and dustproof protection, it supports up to 6,000 deep-cycle charge-discharge cycles.
A-grade battery cells are meticulously selected to ensure a 10-year service life
Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit
Cloud monitoring service, 24 hours to grasp the battery situation at any time
Suitable for RVs, camping, and yachts, this compact and portable device offers convenient mobility
Large capacity, high circulation, safe and stable
| Product Model | D112007 | D112020 | D112050 | D112075 | D112100 | D112150 | D112200 | D112300 |
|---|---|---|---|---|---|---|---|---|
| Nominal Voltage | 12.8V | 12.8V | 12.8V | 12.8V | 12.8V | 12.8V | 12.8V | 12.8V |
| Battery Capacity | 89.6WH | 253WH | 640WH | 960WH | 1280WH | 1920WH | 2560WH | 3840WH |
| Nominal Capacity Energy | 7Ah | 20Ah | 50Ah | 75Ah | 100Ah | 150Ah | 200Ah | 300Ah |
| Operating Voltage | 10V- 14.6V | 10V- 14.6V | 10V- 14.6V | 10V- 14.6V | 10V- 14.6V | 10V- 14.6V | 10V- 14.6V | 10V- 14.6V |
| Maximum Charging Current | 7A | 20A | 50A | 75A | 100A | 100A | 100A | 100A |
| Maximum Discharge Current | 7A | 20A | 50A | 75A | 100A | 100A | 100A | 100A |
| Cell Type | 32800 | 2265146 | 26148134 | 32140 | 50160119 | 42173205 | 54173200 | 71173204 |
| Housing Material | Plastics | Plastics | Plastics | Plastics | Plastics | Plastics | Plastics | Plastics |
| Dimensions | 150*65*94±2mm | 176*166*125mm | 299*138*208mm | 256*165*210mm | 256*165*210mm | 337*180*212mm | 337*180*212mm | 522*240*218mm |
| Weight | 1.05Kg | 2.5Kg | 6Kg | 7.3Kg | 10.5Kg | 16Kg | 22Kg | 30.5Kg |
