Stacked-Mounted Storage Batteries
Supports parallel use with multiple units and features a quick-connect plug for effortless expansion
Natural cooling reduces the power consumption of the entire model
A-grade battery cells are meticulously selected to ensure a 10-year service life
The modular design is easy to install and easy to maintain
Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit
Cloud monitoring service, 24 hours to grasp the battery situation at any time
The unique vertical standing design, the moving pulley is easy to move
Large capacity, high circulation, safe and stable
| Product Model | DCA 502 | DCA 503 | DCA 504 |
|---|---|---|---|
| Rated Voltage | 51.2V | 51.2V | 51.2V |
| Rated Capacity | 200Ah | 300Ah | 400Ah |
| Rated Energy | 10240Wh | 15360Wh | 20480Wh |
| Max. Charging Current | 100A | 200A | 200A |
| Max. Discharging Current | 100A | 200A | 200A |
| Peak Charging Current | 110A (3S) | 220A (3S) | 220A (3S) |
| Peak Discharging Current | 110A (3S) | 220A (3S) | 220A (3S) |
| Breaker Current | 120A | 400A | 400A |
| Battery Type | LFP | LFP | LFP |
| Max. Charging Voltage | 57.6V | 57.6V | 57.6V |
| Over Discharge Voltage | 40V | 40V | 40V |
| Weight | 80Kg | 160Kg | 240Kg |
| Dimensions (L*W*H) | 610*440*665±4mm | 610*440*825±4mm | 610*440*985±4mm |
